1. 360° Planetary Stirring System
Adopts professional planetary mixing structure that simulates manual stir-frying. It fully contacts materials without dead ends, ensuring even heating and effectively avoiding burning. Stirring speed is adjustable from 0–60 rpm for different recipes.
2. High Heating Efficiency & Energy Saving
Equipped with powerful heating system, heating speed is 30% faster than traditional pots. Precise temperature control up to ±2°C ensures stable cooking. It greatly reduces energy consumption and improves production efficiency.
3. Food-Grade 304 Stainless Steel Structure
All parts in contact with food are made of food-grade 304 stainless steel, meeting international food safety standards. Polished surface is easy to clean and maintain, ensuring hygienic production and long service life.
4. Intelligent Automatic Control
User-friendly PLC control panel supports automatic stirring, temperature setting, timing and discharging. One operator can run the whole machine easily, reducing labor cost and ensuring consistent product quality.
5. Automatic Discharge & Easy Operation
Supports automatic hydraulic tilting discharge, fast and labor-saving. The mixing arm is detachable for easy cleaning. Suitable for long-term continuous work, widely used in various food processing lines.
| Model | 100L | 200L | 300L | 400L | 500L | 600L |
| Working Volume | 100L | 200L | 300L | 400L | 500L | 600L |
| Pot Diameter | Φ700mm | Φ800mm | Φ900mm | Φ1000mm | Φ1100mm | Φ1200mm |
| Mixing Type | Planetary + scraping bottom & side, no dead angle | |||||
| Speed Control | Variable frequency, 0–60rpm adjustable | |||||
| Stirring Motor | 1.5kW | 1.5kW | 2.2kW | 2.2kW | 3kW | 3kW |
| Heating Power | 18–24kW | 24–30kW | 30–36kW | 36–40kW | 40–45kW | 45–50kW |
| Heating Mode | Gas / Electric / Steam / Induction (optional) | |||||
| Discharge | Hydraulic automatic tilting | |||||
| Material | Food-grade 304 stainless steel | |||||
| Power Supply | 380V 50Hz 3-phase（Customization） | |||||
| Dimensions (L×W×H) | about1450×900×1700 | about1550×1000×1750 | about1650×1100×1850 | about1750×1200×1950 | about1850×1300×2050 | about1950×1400×2150 |
| Net Weight | about280kg | about350kg | about420kg | about490kg | about560kg | about630kg |
1. Sauce & Condiment Production
Ideal for chili sauce, tomato sauce, bean paste, curry paste and other condiments. The planetary stirring system ensures even heating and no burning, greatly improving taste and quality for large-scale sauce production.
2. Filling & Meat Processing
Widely used for mooncake filling, pastry filling, meat stuffing, bean paste and jam. It mixes evenly with controllable temperature, suitable for food factories and central kitchens making high-quality fillings.
3. Catering & Central Kitchens
Perfect for school canteens, restaurant chains and central kitchens. It can cook dishes, soup, porridge and braised food automatically, saving labor and ensuring consistent taste for mass catering.
4. Candy & Snack Food
Suitable for peanut brittle, sesame candy, milk fudge and other snacks. With precise temperature control and gentle mixing, it protects raw materials and produces glossy, good-shaped products efficiently.
Operation Steps
1. Check power, heating system and stirring device before use.
2. Put raw materials into the pot and set heating temperature and stirring speed.
3. Start automatic stirring and heating; the machine runs intelligently without burning.
4. After processing, stop heating and stirring first, then discharge automatically.
5. Clean the pot body and stirring parts after cooling for next use.
A: The whole machine adopts food-grade 304 stainless steel, which is safe, hygienic, corrosion-resistant and easy to clean. It fully meets international food processing standards.
A: It is widely used for sauces, fillings, soups, candy, chili oil, meat and vegetable dishes. The planetary mixing system ensures even heating without burning.
A: With automatic control panel, it supports automatic stirring, heating and timing. The mixing arm is detachable, making cleaning fast and convenient, saving labor cost.
A: We provide electric, gas, steam and electromagnetic heating options. You can choose the most suitable type according to your factory energy supply and production needs.
A: The unique planetary stirring structure simulates manual stir-frying, with 360° full coverage. It ensures uniform mixing and heating, greatly improving product quality and consistency.
